Single Straw Automatic Position Packing Machine
Inquiry Basket
OEM：
Available
Sample：
Available
Port：
Ningbo
Payment：
PayPal,VISA,MasterCard,Western Union,L/C,T/T
Place of Origin：
China
Shipping：
Sea freight · Land freight · Air freight
Supply Ability：
300 unit per Year
Product Details
Single Straw Automatic Position Packing Machine: This machine is an essential drinking straw packing machine.
TECHNICAL CHARACTERISTICS:
1. Packing, filling and packing individual drinking straws, one cut at a time.
2. Automatic product counting and alarm.
3. The packaging length can be adjusted freely by calibration, paper and BOPP film (or paper/film with logo).
4. You can pack 150~260mm length straws in the same diameter without changing any spare parts. You can pack many straws of different diameters by changing some spare parts.
5.Use three sets of servo motor system to drive, PLC control, touch screen can set any data to package different length straw.
6. High speed color calibration system. precise position with pattern.
7. Temperature module system to control the heating temperature.
8. Stainless steel work table.
Single Straw Automatic Position Packing Machine
| Item | KD-31D |
| Speed | 400-500pcs/min |
| main cutting motor | SERVOMOTORES 0.8KW |
| Main wrap motor | SERVOMOTORES 0.4KW |
| Main pushing motor | SERVOMOTORES 0.4KW |
| Hopper power | 90w |
| Heating power | 2*200w (use BOPP) |
| Packing material | Papel, BOPP film |
| Width of material | Papel: 25-33 mm plastic film: 25-60 mm |
| Straw diamter | 4mm—12mm |
| Straw length | 150-260mm |
| weight | 450kgs |
| Machine size | 1250mm X 1800mm |
| Automatic counter | 1 piece |
| Conveyer belt | 1 piece |
| Touch screen | 1 piece |
| PLC | 1 piece |
| Temperature control module | 1 piece |
| Photocell system | 1 piece |
PP drinking straw machines warehouse
Shipment
shipment of plastic bag machine
If you only buy one machine,we will pack machine with wooden pack,and loading container with Less Than Container Load（LCL）.
If you buy one container machines,we will pack machine with stretch film and loading container directly (FCL full container load).
Loading Drinking Straw Machine Warehouse into container
instalment service
install machines in customer factory
Machine parts supplier
Our Main parts cooperator as following brand,but standard parts all made from China.
Material supplier
How To Find Polyethelene For Blown Film Extrusion.
Extrusion Film Extrusion use Polyethelene,such as
Low Density Polyethylene(LDPE),High Density Polyethylene(HDPE) and Linear Low Density Polyethylene(LLDPE),Polypropylene(PP).
Below are big brand material supplier in the world,they open office all over the world,you can check them in local market.
1.Sabic Saudi Basic Industries Corporation
2.ExxonMobil Chemical Company
3.Dow Chemical Company
